Automatic Trim Tabs Smart Tabs – complete system
The patented Smart Tabs form a unique automatic trim and stabilization system for motorboats. Unlike electric or hydraulic trim tabs, these operate completely automatically, without switches or expensive installation.
The nitrogen-filled cylinders push the trim tabs down at low speeds and automatically lift them horizontally at higher speeds. The tabs are continuously under pressure and function as shock absorbers, constantly adapting to boat speed, balance, and sailing conditions.
The result is a clear improvement in sailing characteristics, faster acceleration, and a more stable boat.
Tip: Measure carefully beforehand whether there is enough space to mount the tabs on your boat's transom.
Specifications
Plate size: 241 x 254 mm
Plate and cylinder material: corrosion-free composite
System: automatic, nitrogen-filled cylinders
Version: complete set
Advantages
Smooth and faster acceleration, ideal for water skiing
Bow stays approximately 40% lower and up to 35% lower while planing, ideal for tubing
Higher top speed and reduction of porpoising and chine walking
Improved handling and more stable ride in any type of water
Lower fuel consumption by up to approximately 11%
Automatically operating trim system without electrical installation
Available models
art. 084200 – complete set with 40 Lb (18 kg) cylinders
Suitable for boat length 12–14 ft, 40–50 hp (4-stroke)
Suitable for boat length 14–16 ft, 50–80 hp (2-stroke)
art. 084210 – complete set with 60 Lb (27 kg) cylinders
Suitable for boat length 15–17 ft, 60–100 hp (4-stroke)
Suitable for boat length 16–18 ft, 60–150 hp (2-stroke)
art. 084220 – complete set with 80 Lb (36 kg) cylinders
Suitable for boat length 18–22 ft, 150–240 hp (2- & 4-stroke)
Installation instructions
Mount the trim tabs on the boat's transom according to the provided instructions. Ensure correct alignment and secure attachment on a flat surface. Check that there is sufficient space for full movement of the tabs.
